DC 48V 2.5A DIN RAIL UPS

DC 48V 2.5A DIN RAIL UPS

Model No.: DR48120-01B

· Rated Output (Max):  56V / 2.5A, 140W
· Battery Charger Included
· Unique Metal Case Design

· L, N and GND Input

· 86% High efficiency

· 2 Years Warranty

· Full Protection
· DC OK LED Indicator
· 100% full load burn-it test
· 48-56V Output Voltage Adjustment



0.00
0.00


Model No.: DR48120-01B

· Rated Output (Max):  56V / 2.5A, 140W
· Battery Charger Included
· Unique Metal Case Design

· L, N and GND Input

· 86% High efficiency

· 2 Years Warranty

· Full Protection
· DC OK LED Indicator
· 100% full load burn-it test
· 48-56V Output Voltage Adjustment






DR48120-01B is a din rail power supply with 1 output channel and 1 battery charger channel, its main output is 48-56V / 2.5A. The PSU is designed based on 140W level.  It could be used for CCTV surveillance / access control / fire alarm and other automation systems.





INPUT

Voltage Range

190 - 265VAC

Frequency Range

50 - 60Hz

OUTPUT

Voltage (AC Mode)

48-56V ±2%

Voltage (Battery Mode)

Same as battery voltage

Rated Current

2.5A

Rated Power (Max.)

140W (with maximum 500mA charging current)

Efficiency (Typ.)

>86%

Ripple & Noise

<480mVp-p

Output Channel

1 Channel

CHARGE

Current

250mA (max.)

Constant voltage mode, charge current decreases when battery voltage increases.

PROTECTION

Input

5A / 250VAC fuse

Overload

3.13A ±5%

Hiccup mode, recovers automatically after fault condition is removed.

Overvoltage

Hiccup mode, recovers automatically after fault condition is removed.

Battery Low Voltage

42V ±2%

PSU shuts down until AC power is reconnected

Short Circuit

Hiccup mode, recovers automatically after fault condition is removed.

ENVIRONMENT

Temperature

Working: -20 - 45

Storage: -30 - 80

Humidity

Working: 20 - 80%RH

Storage: 10 - 90%RH

LED INDICATOR

Green

On

AC supplies

Yellow

On

Battery supplies

Flashing

Battery charging

SAFETY & EMC

EMC Standards

EN 55022: 2010, EN 55024: 2010, EN 61000-3-2: 2014, EN 61000-3-3: 2013

LVD Standards

EN 62368-1-2014-A11-2017

PLASTIC BOX & PACKING

Default Plastic Box

43mm x 124mm x 113mm, can pack with a 12V 7Ah Lead Acid battery externally

Packing

412*285*275mm / CTN, 30pcs / CTN
