DC 24V 1A Din Rail

Model No.: DR24024-01C

· Rated Output (Max): 28V /1A, 28W

· Low Profile Plastic Case, Step Shape

· Class II, Double Insulation

· 86% High efficiency

· 2 Years Warranty

· Full Protection
· DC OK LED Indicator
· 100% full load burn-it test
· 24-28V Output Voltage Adjustment

List price：￥ 0.00

Price：￥ 0.00

Model No.: DR24024-01C

· Rated Output (Max): 28V /1A, 28W

· Low Profile Plastic Case, Step Shape

· Class II, Double Insulation

· 86% High efficiency

· 2 Years Warranty

· Full Protection
· DC OK LED Indicator
· 100% full load burn-it test
· 24-28V Output Voltage Adjustment

DR24024-01C is a din rail power supply with 1 output channels, its main output is 24-28V / 1A. The PSU is designed based on 28W level. It could be used for CCTV surveillance / access control / fire alarm and other security systems.

INPUT	Voltage Range	190 - 265VAC
	Frequency Range	50 - 60Hz
OUTPUT	Voltage (AC Mode)	24-28V ±2% (Adjustable)
	Rated Current	1A
	Rated Power (Max.)	28W
	Efficiency (Typ.)	>86%
	Ripple & Noise	<240mVp-p
	Output Channel	1 Channel
PROTECTION	Input	2A / 250VAC fuse
	Overload	Hiccup mode, recovers automatically after fault condition is removed.
	Over Voltage	Hiccup mode, recovers automatically after fault condition is removed.
	Short Circuit	Hiccup mode, recovers automatically after fault condition is removed.
ENVIRONMENT	Temperature	Working: -20 - 45℃	Storage: -30 - 80℃
	Humidity	Working: 20 - 80%RH	Storage: 10 - 90%RH
LED INDICATOR	Green	On	DC OK
SAFETY & EMC	EMC Standards	EN 55022: 2010, EN 55024: 2010, EN 61000-3-2: 2014, EN 61000-3-3: 2013
	LVD Standards	EN 62368-1-2014-A11-2017
PLASTIC BOX & PACKING	Default Plastic Box	27mm x 93mm x 56mm
	Packing	34219022mm / CTN, 50pcs / CTN

Download:
